ISR4221/K9

Cisco ISR 4221 (2GE,2NIM,8G FLASH,4G DRAM,IPB)

Warranty: 1 year Networking Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex etc
Repairs: We offer repair service when necessary
Exchange: Exchange credit for your defective unit available
Send Inquiry
描述

描述

ISR4221/K9 Overview

Cisco 4221 Integrated Services router is design to deliver advanced services to the small enterprise branch environment. It delivers 35Mbps thoughtput by default. With pay-as-you-grow performance, you can increase forwarding capacity to 75Mbps by buying licenses.





Specification

Specification

Cisco ISR4221/K9 Specification

Aggregate Throughput

35 Mbps to 75 Mbps

Total onboard WAN or LAN 10/100/1000 ports

2

RJ-45-based ports

2

SFP-based ports

1

Enhanced service-module slots

0

Doublewide service-module slots

0

NIM slots

2

OIR (all I/O modules)

No

Onboard ISC slot

No

Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM

(Combined control/services/data planes)

4 GB

Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)

4 GB

Default memory DDR3 ECC DRAM (data plane)

NA

Maximum memory DDR3 ECC DRAM (data plane)

NA

Default memory DDR3 ECC DRAM (control/services plane)

NA

Maximum memory DDR3 ECC DRAM (control/services plane)

NA

Default flash memory

8 GB

Maximum flash memory

8 GB

External USB 2.0 slots (type A)

1

USB console port -type B mini (up to 115.2 kbps)

0

Serial console port – RJ45 (up to 115.2 kbps)

1 (combo CON/AUX port)

Serial auxiliary port – RJ45

(up to 115.2 kbps)

1 (combo CON/AUX port)

Power-supply options

External: AC Only

Redundant power supply

N/A

AC input voltage

100 to 240 VAC autoranging

AC input frequency

47 to 63 Hz

AC input current range, AC power supply (maximum)

1.5 to 0.6A

AC input surge current

90 A peak and less than 3 Arms per half cycle

Typical power (no modules) (watts)

24

Maximum power with AC power supply (watts)

90

Maximum power with PoE power supply (platform only) (watts)

NA (no PoE support)

Maximum endpoint PoE power available from PoE power supply (watts)

NA (no PoE support)

SMARTnet

SMARTnet

Product Name Detail
CON-OSE-ISR4221K SNTC-8X5X4OS Cisco ISR 4221 (2GE,
CON-OSP-ISR4221K SNTC-24X7X4OS Cisco ISR 4221 (2GE.
CON-OS-ISR4221K SNTC-8X5XNBDOS Cisco ISR 4221 (2GE,
CON-S2P-ISR4221K SNTC-24X7X2 Cisco ISR 4221 (2GE.
CON-SMBS-ISR4221K CSCO SUP ESS 8X5XNBD ISR 4221 (2GE.2NIM.4G FLASH.4G DRAM.IPB
CON-SNTE-ISR4221K SNTC-8X5X4 Cisco ISR 4221 (2GE.
CON-SNTP-ISR4221K SNTC-24X7X4 Cisco ISR 4221 (2GE.
CON-SNT-ISR4221K SNTC-8X5XNBD Cisco ISR 4221 (2GE.
CON-SW-ISR4221K SNTC-NO RMA Cisco ISR 4221 (2GE.
CON-3SNTP-ISR4221K 3YR SNTC 24X7X4 Cisco ISR 4221 (2GE.
CON-3SNT-ISR4221K 3YR SNTC 8X5XNBD Cisco ISR 4221 (2GE.



Length of contract required :
 All
1 Year SMARTnet
 3 Year SMARTnet
 5 Year SMARTnet
Shipping&Payment

Shipping&Payment

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

Delivery Options Estimated Delivery Time
 DHL 2-4 business days
 Fedex 2-4 business days
 Hong Kong EMS 5-10 business days
 Hong Kong Air Parcel 10-20 business days
 By Sea 10-20 business days

Notice:

Above mentioned information are just for your reference only, we will keep you posted for the tracking delivery schedule.

Deliver to port:
Itech Smartnet Limited will quote all destination charge prior once we have confirmed order.

Deliver to door:
Itech Smartnet Limited is responsible for transporting goods to door after you have made the payment.

Payment Methods

Warranty

Warranty

100% Low Price Guarantee:

Itech Smartnet Limited provides high-quality products at low wholesale price.

100% Quality Assurance:

All items are ORIGINAL and GENUINE only.
Item conditions are “New Sealed” or “Used / Refurbished”.
Used & refurbished items are fully tested with good conditions by Cisco-certified Engineers.

Free CCIE Technical Support:

Our FREE Cisco CCIE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee:

You can contact our customer service team to exchange or return any product that you bought from us to enjoy the warranty.

Flexible Secure Payment & Shipment:

Verified authorization: Mcafee Secure, VeriSign Secured.

Return Material Authorization (RMA) Process:

 Standard Hardware Warranty Policy:

Original new sealed Cisco product: 1 Year
Used Cisco product: 3 Months

The Support Contacts:

If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can’t correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
