ISR4321/K9
Next product
ISR4431-SEC/K9

ISR4431-AX/K9

Cisco ISR 4431 AX Bundle with APP and SEC license

Warranty: 1 year Networking Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex etc
Repairs: We offer repair service when necessary
Exchange: Exchange credit for your defective unit available
Send Inquiry
分类：
描述

描述

ISR4431-AX/K9 Overview

ISR4431-AX/K9 integrated router combines high-performance, scalability, Data Center features and smart router is made to run multiple services. This is the only router in industry separates control data and services planes, so the benefits are numerous. With pay-as-you-grow performance, you can increase forwarding capacity when needed, you only pay for the performance you need. The ISR4431-AX/K9 runs multi-core, multi-threaded advanced secruity IOS-XE operating system to enable both WAN link security and MPLS and OTV services. Full featured WAN optimization with that run native on the motherboard without affecting performance, management and other capabilities. According to the scalability, ISR 4431 designed as a layer 7 router basically, the advanced network services enable the branch to utilize the WAN intelligently is really what ISR 4400 series all about.The Cisco ISR 4431 is the ultimate application delivery platform to mid-size or even large branch offices. This is literally routing redefined.





Specification

Specification

ISR4431-AX/K9 Specification

Description

Cisco ISR 4431 Advanced services router (2GE,2NIM,1SM,4G FLASH,4G DRAM,MPLS, OTV)

Aggregate Throughput

500Mbps to 1Gbps

Total onboard WAN or LAN 10/100/1000 ports

4

RJ-45-based ports

4

SFP-based ports

4

Enhanced service-module slots

0

Doublewide service-module slots

0

NIM slots

3

OIR (all I/O modules)

Yes

Onboard ISC slot

1

Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM

(Combined control/services/data planes)

NA

Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)

NA

Default memory DDR3 ECC DRAM (data plane)

2 GB

Maximum memory DDR3 ECC DRAM (data plane)

2 GB

Default memory DDR3 ECC DRAM (control/services plane)

4 GB

Maximum memory DDR3 ECC DRAM (control/services plane)

16 GB

Default flash memory

8 GB

Maximum flash memory

32 GB

External USB 2.0 slots (type A)

2

USB console port -type B mini (up to 115.2 kbps)

1

Serial console port – RJ45 (up to 115.2 kbps)

1

Serial auxiliary port – RJ45 (up to 115.2 kbps)

1

Power-supply options

Internal: AC, DC, and PoE

Redundant power supply

Internal: AC, DC, and PoE

AC input voltage

100 to 240 VAC autoranging

AC input frequency

47 to 63 Hz

AC input current range, AC power supply (maximum)

3 to 1.3A

AC input surge current

60 A peak and less than 5 Arms per half cycle

Typical power (no modules) (watts)

65

Maximum power with AC power supply (watts)

250 (no PoE)

Maximum power with PoE power supply (platform only) (watts)

500 with PoE redundant

Maximum endpoint PoE power available from PoE power supply (watts)

250 W with optional redundancy
SMARTnet

SMARTnet



Product Name Detail
CON-OSE-ISR4431A ONSITE 8X5X4 Cisco ISR 4431 AX Bundle with APP and SEC licen
CON-OSP-ISR4431A ONSITE 24X7X4 Cisco ISR 4431 AX Bundle with APP and SEC lice
CON-OS-ISR4431A ONSITE 8X5XNBD Cisco ISR 4431 AX Bundle with APP and SEC lic
CON-PREM-ISR4431A ONSITE 24X7X2 Cisco ISR 4431 AX Bundle with APP and SEC lice
CON-S2P-ISR4431A SMARTNET 24X7X2 Cisco ISR 4431 AX Bundle with APP and SEC li
CON-SNTE-ISR4431A SMARTNET 8X5X4 Cisco ISR 4431 AX Bundle with APP and SEC lic
CON-SNTP-ISR4431A SNTC-24X7X4 Cisco ISR 4431 AX Bundle with APP and SEC li
CON-SNT-ISR4431A SMARTNET 8X5XNBD Cisco ISR 4431 AX Bundle with APP and SEC l
CON-SW-ISR4431A CISCO BASE Cisco ISR 4431 AX Bundle with APP and SEC license
CON-3OSP-ISR4431A 3YR SMARTNET24X7X4OS Cisco ISR 4431 AX Bundle with APP and S
CON-3SNTP-ISR4431A 3YR SNTC 24X7X4 Cisco ISR 4431 AX Bundle with APP and SE



Length of contract required :
 All
 1 Year SMARTnet
 3 Year SMARTnet
 5 Year SMARTnet




Shipping&Payment

Shipping&Payment

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

Delivery Options Estimated Delivery Time
 DHL 2-4 business days
 Fedex 2-4 business days
 Hong Kong EMS 5-10 business days
 Hong Kong Air Parcel 10-20 business days
 By Sea 10-20 business days

Notice:

Above mentioned information are just for your reference only, we will keep you posted for the tracking delivery schedule.

Deliver to port:
Itech Smartnet Limited will quote all destination charge prior once we have confirmed order.

Deliver to door:
Itech Smartnet Limited is responsible for transporting goods to door after you have made the payment.

Payment Methods
Warranty

Warranty

100% Low Price Guarantee:

Itech Smartnet Limited provides high-quality products at low wholesale price.

100% Quality Assurance:

All items are ORIGINAL and GENUINE only.
Item conditions are “New Sealed” or “Used / Refurbished”.
Used & refurbished items are fully tested with good conditions by Cisco-certified Engineers.

Free CCIE Technical Support:

Our FREE Cisco CCIE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee:

You can contact our customer service team to exchange or return any product that you bought from us to enjoy the warranty.

Flexible Secure Payment & Shipment:

Verified authorization: Mcafee Secure, VeriSign Secured.

Return Material Authorization (RMA) Process:

 Standard Hardware Warranty Policy:

Original new sealed Cisco product: 1 Year
Used Cisco product: 3 Months

The Support Contacts:

If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can’t correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
