ISR4321-VSEC/K9 Overview

Cisco 4321 Integrated Services router is design to deliver advanced services to the small enterprise branch environment. It delivers 50Mbps thoughtput by default. ISR4321-VSEC/K9 is the Cisco ISR 4321 router with Bundle w/UC & SEC License, and CUBE-10.

Specification

ISR4321-VSEC/K9 Specification
Description	Cisco ISR 4321 Bundle w/UC & SEC License. CUBE-10
Aggregate Throughput	50 Mbps to 100 Mbps
Total onboard WAN or LAN 10/100/1000 ports	2
RJ-45-based ports	2
SFP-based ports	1
Enhanced service-module slots	0
Doublewide service-module slots	0
NIM slots	2
OIR (all I/O modules)	Yes
Onboard ISC slot	1
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes)	4 GB
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)	8 GB
Default memory DDR3 ECC DRAM (data plane)	NA
Maximum memory DDR3 ECC DRAM (data plane)	NA
Default memory DDR3 ECC DRAM (control/services plane)	NA
Maximum memory DDR3 ECC DRAM (control/services plane)	NA
Default flash memory	4 GB
Maximum flash memory	8 GB
External USB 2.0 slots (type A)	1
USB console port -type B mini (up to 115.2 kbps)	1
Serial console port – RJ45 (up to 115.2 kbps)	1
Serial auxiliary port – RJ45 (up to 115.2 kbps)	1
Power-supply options	External: AC and PoE
Redundant power supply	N/A
AC input voltage	100 to 240 VAC autoranging
AC input frequency	47 to 63 Hz
AC input current range, AC power supply (maximum)	1.5 to 0.6A
AC input surge current	90 A peak and less than 3 Arms per half cycle
Typical power (no modules) (watts)	36
Maximum power with AC power supply (watts)	125
Maximum power with PoE power supply (platform only) (watts)	260
Maximum endpoint PoE power available from PoE power supply (watts)	120

SMARTnet

Product Name	Detail
CON-OSE-IR4321VS	SNTC-8X5X4OS Cisco ISR 4321 Bundle with UC SEC Lice
CON-OSP-IR4321VS	SNTC-24X7X4OS Cisco ISR 4321 Bundle with UC SEC Lice
CON-OS-IR4321VS	SNTC-8X5XNBDOS Cisco ISR 4321 Bundle with UC SEC Lice
CON-S2P-IR4321VS	SNTC-24X7X2 Cisco ISR 4321 Bundle with UC SEC Lice
CON-SNTE-IR4321VS	SNTC-8X5X4 Cisco ISR 4321 Bundle with UC SEC Lice
CON-SNTP-IR4321VS	SNTC-24X7X4 Cisco ISR 4321 Bundle with UC SEC Lice
CON-SNT-IR4321VS	SNTC-8X5XNBD Cisco ISR 4321 Bundle with UC SEC Lice
CON-SW-IR4321VS	SNTC-NO RMA Cisco ISR 4321 Bundle with UC SEC Lice
CON-3OSP-IR4321VS	3YR SNTC 24X7X4OS Cisco ISR 4321 Bundle wUC SEC License
CON-3SNTP-IR4321VS	3YR SNTC 24X7X4 Cisco ISR 4321 Bundle wUC SEC License

Length of contract required :

All 3 Year SMARTnet
5 Year SMARTnet

Shipping&Payment

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

Delivery Options	Estimated Delivery Time
DHL	2-4 business days
Fedex	2-4 business days
Hong Kong EMS	5-10 business days
Hong Kong Air Parcel	10-20 business days
By Sea	10-20 business days

Notice:

Above mentioned information are just for your reference only, we will keep you posted for the tracking delivery schedule.

Deliver to port:
Itech Smartnet Limited will quote all destination charge prior once we have confirmed order.

Deliver to door:
Itech Smartnet Limited is responsible for transporting goods to door after you have made the payment.

Payment Methods

Warranty

100% Low Price Guarantee:

Itech Smartnet Limited provides high-quality products at low wholesale price.

100% Quality Assurance:

All items are ORIGINAL and GENUINE only.
Item conditions are “New Sealed” or “Used / Refurbished”.
Used & refurbished items are fully tested with good conditions by Cisco-certified Engineers.

Free CCIE Technical Support:

Our FREE Cisco CCIE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee:

You can contact our customer service team to exchange or return any product that you bought from us to enjoy the warranty.

Flexible Secure Payment & Shipment:

Verified authorization: Mcafee Secure, VeriSign Secured.

Return Material Authorization (RMA) Process:

Standard Hardware Warranty Policy:

Original new sealed Cisco product: 1 Year
Used Cisco product: 3 Months

The Support Contacts:

If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can’t correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Warranty:	1 year Networking Warranty Included
Shipping:	Worldwide shipping via DHL, UPS, Fedex etc
Repairs:	We offer repair service when necessary
Exchange:	Exchange credit for your defective unit available
